AES Equivalent Mechanical Seals
AES Mechanical Seals
Our range of high quality mechanical seals include types that offer the same make-up and sizing as AES Seal's®.
AES Seals® are a specialist in the design and manufacture of mechanical seals and support systems. Their mechanical seals are used in a wide range of pumps and rotating equipment worldwide to prevent liquids and gases escaping into the environment. They have been manufacturing mechanical seals to suit all industries for over 20 years so their seals can be found in a wide array of equipment, new and old.
The most common types of AES® Mechanical seal equivalents we provide are as follows:
| AES® Model | Totally Seals Equivalent |
| AES® Type N-B03 | Type 70 |
| AES® Type N-B03U | Type 75 |
| AES® Type N-B04 | Type 60 |
| AES® Type N-B05 | Type 14DIN |
| AES® Type N-B05S | Type 14DINS |
| AES® Type N-B052 | Type 142DIN |
| AES® Type N-B052S | Type 142DINS |
| AES® Type N-B053 | Type 143DIN |
| AES® Type N-B053S | Type 143DINS |
| AES® Type N-B06 | Type 28 |
| AES® Type N-B060 | Type 282 |
| AES® Type N-B07 | Type 1724 |
| AES® Type N-B07S | Type 1724S |
| AES® Type N-B07SL | Type 1724L |
| AES® Type N-B0H | Type 66 |
| AES® Type N-BP02 | Type 1520 |
| AES® Type N-BP04 | Type 1511 |
| AES® Type N-BP05 | Type 1522 |
| AES® Type N-C01 | Type CLAM |
| AES® Type N-C02 | Type 96 |
| AES® Type N-C03 | Type 97 |
| AES® Type N-M01 | Type 1609 |
| AES® Type N-M01S | Type 1609S |
| AES® Type N-M02 | Type 1609B |
| AES® Type N-M02S | Type 1609BS |
| AES® Type N-M03 | Type 1659 |
| AES® Type N-M03S | Type 1659S |
| AES® Type N-M04 | Type 1659B |
| AES® Type N-M04S | Type 1659BS |
| AES® Type N-M05 | Type 1645 |
| AES® Type N-M05S | Type 1645S |
| AES® Type N-M06 | Type 1645B |
| AES® Type N-M06S | Type 1645BS |
| AES® Type N-M07 | Type 50 |
| AES® Type N-M010 | Type 40 |
| AES® Type N-M010S1 | Type 1663 |
| AES® Type N-M010S2 | Type 1663A |
| AES® Type N-M010S3 | Type 1662 |
| AES® Type N-M010S4 | Type 1691 |
| AES® Type N-M010SA | Type 42 |
| AES® Type N-MP07 | Type 912 |
| AES® Type N-P01 | Type 10 |
| AES® Type N-P01U | Type A1 |
| AES® Type N-P02 | Type 20 |
| AES® Type N-P02C | Type CAR |
| AES® Type N-P02G | Type 207 |
| AES® Type N-P02U | Typa A2 |
| AES® Type N-P03 | Type 24 |
| AES® Type N-P04 | Type 11 |
| AES® Type N-P04U | Type A4 |
| AES® Type N-P05 | Type 22 |
| AES® Type N-P05U | Type A5 |
| AES® Type N-P06 | Type 26 |
| AES® Type N-P07 | Consult Us |
| AES® Type N-P08 | Type 95 |
| AES® Type N-P080 | Type 98 |
| AES® Type N-P09 | Type 94 |
| AES® Type N-P09S | Type B94 |
| AES® Type N-P010 | Type 293 |
| AES® Type N-P011 | Type 89 |
| AES® Type N-S01 | Type 8.STD |
| AES® Type N-S02 | Type 8.DINL |
| AES® Type N-S03 | Type 8.DINS |
| AES® Type N-S04 | Type 24 SEAT |
| AES® Type N-S040 | Type 19B SEAT |
| AES® Type N-S05 | Type 24.DINL |
| AES® Type N-S06 | Type 24.DINS |
| AES® Type N-S07 | Type 21 SEAT |
| AES® Type N-S070 | Type 31 SEAT |
| AES® Type N-S08 | Type 25 SEAT |
| AES® Type N-S09 | Type 23 SEAT |
| AES® Type N-S010 | Type 24.BEZL |
| AES® Type N-S011 | Type 32 SEAT |
| AES® Type N-S013 | Type 24.BEZS |
| AES® Type N-S0E | Type 1640 |
| AES® Type N-S0S / S0SS | Type 86 |
| AES® Type N-S0Z | Consult Us |
| AES® Type N-SAIH | Type 41 |
| AES® Type N-T01 | Type 8 |
| AES® Type N-T01.DIN | Type 8DIN |
| AES® Type N-T01A | Type 8W |
| AES® Type N-T01DB | Type 82 |
| AES® Type N-T01F | Consult Us |
| AES® Type N-T01SA | Type 81 |
| AES® Type N-T02 | Type 8B |
| AES® Type N-T03 | Type 12 |
| AES® Type N-T03.DIN | Type 12DIN |
| AES® Type N-T04 | Type 13 |
| AES® Type N-T04.DIN | Type 13DIN |
| AES® Type N-T05 Range | Type 06 Range |
| AES® Type N-T06D | Type 135 |
| AES® Type N-T07 | Type 9 |
| AES® Type N-T07D | Type 9+8.DINL |
| AES® Type N-T0R | Type 29 |
| AES® Type N-T0W | Type 16 |
| AES® Type N-T0WD | Type 16DOUB |
| AES® Type N-T0WDW | Type 297 |
| AES® Type N-T0WP | Type 16.PLUS |
| AES® Type N-W01 | Type 1688 |
| AES® Type N-W01TL | Type 1688Z |
| AES® Type N-W02 | Type 1688L |
| AES® Type N-W03 | Type 1688W |
| AES® Type N-W04 | Type 1688Y |
| AES® Type N-W06 | Type 1650 |
| AES® Type N-W07D | Type 1677 |
| AES® Type N-W07DM | Type 1677M |
| AES® Type N-W07DMB | Type 1678 |
| AES® Type N-W07SD | Type 1633 |
| AES® Type N-W08 | Type 295 |
| AES® Type N-W09 | Type 1655 |
| AES® Type N-W010 | Type 294 |
| AES® Type N-W011 | Type 1683 |
| AES® Type N-W014 | Type 1632 |
| AES® Type N-W015 | Type 1651 |
| AES® Type N-W016 | Type 1680 |
| AES® Type N-W017 | Type 1649 |
| AES® Type N-W0FA/W0FC | Type 1676 |
| AES® Type N-W0FB | Consult Us |
Who Are AES Seal?
AES Seal is a global specialist in the design and manufacture of mechanical seals and support systems. The company is dedicated to improving the reliability of rotating equipment and reducing maintenance costs through innovative sealing solutions. They operate in a wide range of industries including oil and gas, food and beverage, water treatment, mining, and pharmaceuticals.
What is the history AES Seal?
AES Seal was founded in 1979 by Chris Rea, starting as a small distribution business in Sheffield. The company has grown significantly over the years, now operating from 235 locations in 104 countries and employing over 1,800 people globally. AES Seal has a history of continuous growth and innovation, expanding its product range and investing heavily in research and development. The company has also been recognized with numerous awards, including 13 Queen’s Awards.
What mechanical seals AES Seal offer?
AES Seal offers a comprehensive range of mechanical seals designed to meet the needs of various industries and applications. Some of their key offerings include:
- Cartridge Seals: Pre-assembled seals that are easy to install and maintain, reducing the risk of installation errors.
- Component Seals: Versatile seals that can be customized to fit specific applications and conditions.
- Gas Seals: Designed for high-pressure and high-temperature applications, particularly in the oil and gas industry.
- Elastomer Bellows Seals: Ideal for applications involving misalignment and axial movement.
- Metal Bellows Seals: Suitable for high-temperature applications and corrosive environments.
- Split Seals: Designed for easy installation and replacement without dismantling equipment.
All brand names are used to illustrate examples of the types of seals that we can replace, we are not in any way affiliated with these companies or stating that we provide genuine parts of aforementioned companies.
