Which type of Multiple Spring seal?

Match your seal with these 2 types:

Identify your seal by matching the parts highlighted in red.

O-Ring Seal

The shaft seal inside the rotary part is an elastomer o-ring.

This is my seal

PTFE Wedge Seal

The shaft seal inside the rotary is a PTFE wedge.

This is my seal

What is a multiple spring seal?

These seals are energised by multiple, small coils that result in higher pressure sealing capabilities. They are commonly used in petrochemical or chemical applications. The multi sprung design allows an even face load to be applied over the face area and butt a number of compression springs.

Our Mechanical Seals range

We can supply replacement seals for most major manufacturers: Eagle Burgmann, John Crane, Roten/Uniten, AES, Alfa Laval, Grundfos, MTU, PAC-Seal, US Seal and more.
